WR12X1802FTL
Availability
Design risk
Price trend
Lead time
Chip resistor, WR12X1802FTL, Walsin Technologies The resistor is constructed in a high grade ceramic body (aluminum oxide). Internal metal electrodes are added at each end and connected by a resistive paste that is applied to the top surface of the substrate. The composition of the paste is adjusted to give the approximate resistance required and the value is trimmed to within tolerance by laser cutting of this resistive layer. Features High reliability and stability Reduced size of final equipment Lower assembly costs Higher component and equipment reliability
| Size Code | 1206 |
| Technology | METAL GLAZE/THICK FILM |
| Construction | Rectangular |
| Package Style (Meter) | SMT |
| Resistor Type | FIXED RESISTOR |
| Tolerance (%) | 1 |
| J-STD-609 Code | e3 |
| Packing Method | TR, PAPER, 7 INCH |
| Terminal Shape | WRAPAROUND |
| Terminal Finish | Matte Tin (Sn) - with Nickel (Ni) barrier |
| Mounting Feature | SURFACE MOUNT |
| Resistance (ohm) | 18000 |
| Additional Feature | FLAME PROOF, LASER TRIMMABLE |
| Package Width (mm) | 1.6 |
| Number of Terminals | 2 |
| Package Height (mm) | 0.55 |
| Package Length (mm) | 3.1 |
| Working Voltage (V) | 200 |
| Rated Temperature (Cel) | 70 |
| Operating Temperature-Max (Cel) | 155 |
| Operating Temperature-Min (Cel) | -55 |
| Rated Power Dissipation (P) (W) | 0.25 |
| Temperature Coefficient (ppm/Cel) | 100 |
