Semiconductors

Amplifiers

Lead Time     12 weeks
Data Sheet     Download TLV2374IPWR datasheet TLV2374IPWR

Quad, 16-V, 3-MHz, RRIO operational amplifier 14-TSSOP -40 to 125

Technical Data

Manufacturer texas instruments inc
MPN TLV2374IPWR
Power NO
Low-Bias YES
Wideband YES
Low-Offset NO
Micropower NO
Technology CMOS
Width (mm) 4.4000
Length (mm) 5.0000
JESD-30 Code R-PDSO-G14
Package Code TSSOP
Sub Category Operational Amplifier
Package Shape RECTANGULAR
Package Style ( Meter ) SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
Surface Mount YES
Terminal Form GULL WING
Amplifier Type General Purpose
J-STD-609 Code e4
Packing Method TR
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Amp Architecture VOLTAGE-FEEDBACK
Voltage Gain-Min 79432.0000
DLA Qualification Not Qualified
Temperature Grade AUTOMOTIVE
Terminal Position DUAL
Programmable Power NO
Number of Functions 4.0000
Number of Terminals 14.0000
Terminal Pitch (mm) 0.6500
Slew Rate-Min (V/us) 1.0000
Slew Rate-Nom (V/us) 2.4000
Package Body Material PLASTIC/EPOXY
Frequency Compensation YES
Seated Height-Max (mm) 1.2000
Supply Voltage-Nom (V) 5.0000
Supply Current-Max (mA) 2.6400
Unity Gain BW-Nom (kHz) 3000.0000
Package Equivalence Code TSSOP14,.25
Moisture Sensitivity Level 1.0000
Supply Voltage Limit-Max (V) 16.5000
Input Offset Voltage-Max (uV) 4500.0000
Peak Reflow Temperature (Cel) 260.0000
Operating Temperature-Max (Cel) 125.0000
Operating Temperature-Min (Cel) -40.0000
Bias Current-Max (IIB) @25C (uA) 0.0001
Common-mode Reject Ratio-Min (dB) 55.0000
Common-mode Reject Ratio-Nom (dB) 72.0000
Average Bias Current-Max (IIB) (uA) 0.0001
Input Offset Current-Max (IIO) (uA) 0.0001
Time@Peak Reflow Temperature-Max (s) 30.0000
Availability In stock
