BC817-40,215
Availability
Design risk
Price trend
Lead time
45 V, 500 mA NPN general-purpose transistors
| Application | SWITCHING |
| JESD-30 Code | R-PDSO-G3 |
| Configuration | SINGLE |
| JEDEC-95 Code | TO-236AB |
| Package Shape | RECTANGULAR |
| Package Style (Meter) | SMALL OUTLINE |
| Surface Mount | YES |
| Terminal Form | GULL WING |
| J-STD-609 Code | e3 |
| VCEsat-Max (V) | 0.7 |
| Terminal Finish | TIN |
| DLA Qualification | Not Qualified |
| Terminal Position | DUAL |
| Number of Elements | 1 |
| Number of Terminals | 3 |
| Package Body Material | PLASTIC/EPOXY |
| Polarity/Channel Type | NPN |
| DC Current Gain-Min (hFE) | 250 |
| Moisture Sensitivity Level | 1 |
| Transistor Element Material | SILICON |
| Peak Reflow Temperature (Cel) | 260 |
| Collector Current-Max (IC) (A) | 0.5 |
| Operating Temperature-Max (Cel) | 150 |
| Operating Temperature-Min (Cel) | -65 |
| Collector-emitter Voltage-Max (V) | 45 |
| Transition Frequency-Nom (fT) (MHz) | 100 |
| Time@Peak Reflow Temperature-Max (s) | 30 |
Submit request
CONTACT REASON
Sourceability North America, LLC
9715 Burnet Rd, Ste 200You can download the user manual and technical specifications for Nexperia BV BC817-40,215 in the documentation section.
45 V, 500 mA NPN general-purpose transistors
As part of the category Semiconductors and subcategory Semiconductors, BC817-40,215 optimizes energy distribution in electronic devices. Its 45 V, 500 mA NPN general-purpose transistors allows minimizing losses and increasing the overall system efficiency.
As a component of the subcategory Semiconductors, BC817-40,215 ensures stable output voltage even when the load changes. Its 45 V, 500 mA NPN general-purpose transistors makes it a reliable element in multi-level power systems.
