Semiconductors

Diodes

Lead Time     10 weeks

General-purpose dual Schottky diode

Technical Data

Manufacturer nexperia
MPN BAS40-05,215
Diode Type RECTIFIER DIODE
Technology SCHOTTKY
Application GENERAL PURPOSE
JESD-30 Code R-PDSO-G3
Configuration COMMON CATHODE, 2 ELEMENTS
JEDEC-95 Code TO-236AB
Package Shape RECTANGULAR
Package Style ( Meter ) SMALL OUTLINE
Surface Mount YES
Terminal Form GULL WING
J-STD-609 Code e3
Terminal Finish TIN
DLA Qualification Not Qualified
Terminal Position DUAL
Number of Elements 2.0000
Number of Terminals 3.0000
Package Body Material PLASTIC/EPOXY
Diode Element Material SILICON
Output Current-Max (A) 0.1200
Moisture Sensitivity Level 1.0000
Peak Reflow Temperature (Cel) 260.0000
Rep Pk Reverse Voltage-Max (V) 40.0000
Operating Temperature-Max (Cel) 150.0000
Screening Level / Reference Standard IEC-60134
Time@Peak Reflow Temperature-Max (s) 30.0000
Availability In stock
