TMS320F28035PAGTR
Availability
Design risk
Price trend
Lead time
C2000™ 32-bit MCU with 60 MHz, 128 KB flash, CLA 64-TQFP -40 to 105
| Bit Size | 32 |
| Technology | CMOS |
| Width (mm) | 10 |
| Length (mm) | 10 |
| Peripherals | BOR, COMPARATOR(3), POR, PWM(18), TIMER(3), WDT |
| Speed (MHz) | 60 |
| ADC Channels | YES |
| Connectivity | CAN, I2C, LIN, SCI, SPI |
| DAC Channels | NO |
| DMA Channels | NO |
| JESD-30 Code | S-PQFP-G64 |
| PWM Channels | YES |
| Package Code | TFQFP |
| Boundary Scan | YES |
| Package Shape | SQUARE |
| Package Style (Meter) | FLATPACK, THIN PROFILE, FINE PITCH |
| Surface Mount | YES |
| Terminal Form | GULL WING |
| A/D Converters | 14-Ch 12-Bit |
| J-STD-609 Code | e4 |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) |
| Address Bus Width | 0 |
| Temperature Grade | INDUSTRIAL |
| Terminal Position | QUAD |
| Number of I/O Lines | 33 |
| Number of Terminals | 64 |
| Program Memory Type | FLASH |
| Terminal Pitch (mm) | 0.5 |
| Data RAM Size (bytes) | 20480 |
| Package Body Material | PLASTIC/EPOXY |
| Seated Height-Max (mm) | 1.2 |
| Supply Voltage-Max (V) | 1.995 |
| Supply Voltage-Min (V) | 1.71 |
| Supply Voltage-Nom (V) | 1.8 |
| External Data Bus Width | 0 |
| Data EEPROM Size (bytes) | 0 |
| Clock Frequency-Max (MHz) | 30 |
| Moisture Sensitivity Level | 3 |
| Program Memory Size (words) | 65536 |
| Program Memory Width (bits) | 16 |
| uPs/uCs/Peripheral ICs Type | MICROCONTROLLER |
| Peak Reflow Temperature (Cel) | 260 |
| Operating Temperature-Max (Cel) | 105 |
| Operating Temperature-Min (Cel) | -40 |
| Screening Level / Reference Standard | AEC-Q100 |
| Time@Peak Reflow Temperature-Max (s) | 30 |
Submit request
CONTACT REASON
Sourceability North America, LLC
9715 Burnet Rd, Ste 200You can download the user manual and technical specifications for Texas Instruments Incorporated TMS320F28035PAGTR in the documentation section.
C2000™ 32-bit MCU with 60 MHz, 128 KB flash, CLA 64-TQFP -40 to 105
As part of the category Semiconductors and subcategory Semiconductors, TMS320F28035PAGTR optimizes energy distribution in electronic devices. Its C2000™ 32-bit MCU with 60 MHz, 128 KB flash, CLA 64-TQFP -40 to 105 allows minimizing losses and increasing the overall system efficiency.
As a component of the subcategory Semiconductors, TMS320F28035PAGTR ensures stable output voltage even when the load changes. Its C2000™ 32-bit MCU with 60 MHz, 128 KB flash, CLA 64-TQFP -40 to 105 makes it a reliable element in multi-level power systems.
