WR04X56R2FTL
Availability
Design risk
Price trend
Lead time
Res Thick Film 0402 56.2 Ohm 1% 0.063W(1/16W) ±100ppm/°C Pad SMD T/R
| Size Code | 0402 |
| Technology | METAL GLAZE/THICK FILM |
| Construction | Rectangular |
| Package Style (Meter) | SMT |
| Resistor Type | FIXED RESISTOR |
| Tolerance (%) | 1 |
| J-STD-609 Code | e3 |
| Packing Method | TR, Paper, 7 Inch |
| Terminal Shape | WRAPAROUND |
| Terminal Finish | Matte Tin (Sn) - with Nickel (Ni) barrier |
| Mounting Feature | SURFACE MOUNT |
| Resistance (ohm) | 56.2 |
| Package Width (mm) | 0.5 |
| Number of Terminals | 2 |
| Package Height (mm) | 0.35 |
| Package Length (mm) | 1 |
| Working Voltage (V) | 50 |
| Rated Temperature (Cel) | 70 |
| Operating Temperature-Max (Cel) | 155 |
| Operating Temperature-Min (Cel) | -55 |
| Rated Power Dissipation (P) (W) | 0.0625 |
| Temperature Coefficient (ppm/Cel) | 100 |
| Width | 0.5 mm |
| Length | 1 mm |
| Moisture Sensitivity Level | 1 |
Submit request
CONTACT REASON
Sourceability North America, LLC
9715 Burnet Rd, Ste 200You can download the user manual and technical specifications for Walsin Technology Corporation WR04X56R2FTL in the documentation section.
Res Thick Film 0402 56.2 Ohm 1% 0.063W(1/16W) ±100ppm/°C Pad SMD T/R
As a typical representative of the subcategory Passives, WR04X56R2FTL is used to control the level of current and voltage in electrical circuits. Its Res Thick Film 0402 56.2 Ohm 1% 0.063W(1/16W) ±100ppm/°C Pad SMD T/R ensures stable resistance, which is critical for precise measurements and component protection.
WR04X56R2FTL from the category Passives by manufacturer Walsin Technology Corporation provides precise current limitation in the scheme. Thanks to its Res Thick Film 0402 56.2 Ohm 1% 0.063W(1/16W) ±100ppm/°C Pad SMD T/R, it contributes to stable operation of electronic devices, preventing overloads and voltage fluctuations.
