Semiconductors

Other Semiconductors

Lead Time     6 weeks
Data Sheet     Download TLV74033PDBVR datasheet TLV74033PDBVR

300-mA low-dropout (LDO) regulator with foldback current limit 5-SOT-23 -40 to 85

Technical Data

Manufacturer TEXAS INSTRUMENTS INC
MPN TLV74033PDBVR
Width (mm) 1.6000
Length (mm) 2.9000
JESD-30 Code R-PDSO-G5
Package Code LSSOP
Adjustability FIXED
Package Shape RECTANGULAR
Package Style ( Meter ) SMALL OUTLINE, LOW PROFILE, SHRINK PITCH
Surface Mount YES
Terminal Form GULL WING
J-STD-609 Code e4
Packing Method TR
Regulator Type FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Outputs 1.0000
Terminal Position DUAL
Number of Functions 1.0000
Number of Terminals 5.0000
Terminal Pitch (mm) 0.9500
Input Voltage-Max (V) 5.5000
Input Voltage-Min (V) 3.8000
Package Body Material PLASTIC/EPOXY
Seated Height-Max (mm) 1.4500
Line Regulation-Max (V) 0.0050
Load Regulation-Max (V) 0.0300
Output Current1-Max (A) 0.3000
Output Voltage1-Max (V) 3.3330
Output Voltage1-Min (V) 3.2670
Output Voltage1-Nom (V) 3.3000
Dropout Voltage1-Max (V) 0.5000
Dropout Voltage1-Nom (V) 0.4600
Package Equivalence Code TSOP5/6,.11,37
Voltage Tolerance-Max (%) 1.0000
Moisture Sensitivity Level 1.0000
Peak Reflow Temperature (Cel) 260.0000
Input Voltage Absolute-Max (V) 6.0000
Operating Temperature-Max (Cel) 125.0000
Operating Temperature-Min (Cel) -40.0000
Operating Temperature TJ-Max (Cel) 85.0000
Operating Temperature TJ-Min (Cel) -40.0000
Time@Peak Reflow Temperature-Max (s) 30.0000
