Lead Time     2 weeks
Data Sheet     Download TXB0104PWR datasheet TXB0104PWR

4-Bit Bidirectional Voltage-Level Shifter with Auto Direction Sensing and +/-15 kV ESD Protect 14-TSSOP -40 to 85

Technical Data

Manufacturer texas instruments inc
MPN TXB0104PWR
Width (mm) 4.4000
Length (mm) 5.0000
JESD-30 Code R-PDSO-G14
Package Code TSSOP
Package Shape RECTANGULAR
Package Style ( Meter ) SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
Surface Mount YES
Terminal Form GULL WING
Delay-Max (ns) 14.2000
J-STD-609 Code e4
Number of Bits 4.0000
Output Polarity TRUE
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
DLA Qualification Not Qualified
Interface IC Type VOLTAGE LEVEL TRANSLATOR
Temperature Grade INDUSTRIAL
Terminal Position DUAL
Number of Functions 1.0000
Number of Terminals 14.0000
Terminal Pitch (mm) 0.6500
Package Body Material PLASTIC/EPOXY
Output Characteristics 3-STATE
Seated Height-Max (mm) 1.2000
Supply Voltage-Max (V) 3.6000
Supply Voltage-Min (V) 0.7800
Supply Voltage-Nom (V) 1.5000
Supply Current-Max (mA) 5.5000
Supply Voltage1-Max (V) 5.5000
Supply Voltage1-Min (V) 1.6500
Supply Voltage1-Nom (V) 1.8000
Package Equivalence Code TSSOP14,.25
Moisture Sensitivity Level 1.0000
Output Low Current-Max (mA) 0.0200
Peak Reflow Temperature (Cel) 260.0000
Operating Temperature-Max (Cel) 85.0000
Operating Temperature-Min (Cel) -40.0000
Time@Peak Reflow Temperature-Max (s) 30.0000
Availability In stock
