LM78M05CDTX/NOPB
Availability
Design risk
Price trend
Lead time
500-mA, 35-V, linear voltage regulator for 5 V 3-TO-252 -40 to 125
| Technology | BIPOLAR |
| Width (mm) | 6.1 |
| Length (mm) | 6.58 |
| JESD-30 Code | R-PSSO-G2 |
| Package Code | TO-252 |
| Adjustability | FIXED |
| Package Shape | RECTANGULAR |
| Package Style (Meter) | SMALL OUTLINE |
| Surface Mount | YES |
| Terminal Form | GULL WING |
| J-STD-609 Code | e3 |
| Packing Method | TR |
| Regulator Type | FIXED POSITIVE SINGLE OUTPUT STANDARD REGULATOR |
| Terminal Finish | Matte Tin (Sn) |
| DLA Qualification | Not Qualified |
| Number of Outputs | 1 |
| Terminal Position | SINGLE |
| Number of Functions | 1 |
| Number of Terminals | 3 |
| Terminal Pitch (mm) | 2.28 |
| Input Voltage-Max (V) | 35 |
| Input Voltage-Min (V) | 7.2 |
| Package Body Material | PLASTIC/EPOXY |
| Seated Height-Max (mm) | 2.55 |
| Line Regulation-Max (V) | 0.100000000000000 |
| Load Regulation-Max (V) | 0.100000000000000 |
| Output Current1-Max (A) | 0.5000 |
| Output Voltage1-Max (V) | 5.2500 |
| Output Voltage1-Min (V) | 4.7500 |
| Output Voltage1-Nom (V) | 5.0000 |
| Dropout Voltage1-Nom (V) | 1.800000000000000 |
| Package Equivalence Code | SMSIP3H,.38,90TB |
| Voltage Tolerance-Max (%) | 5 |
| Moisture Sensitivity Level | 2 |
| Peak Reflow Temperature (Cel) | 260 |
| Input Voltage Absolute-Max (V) | 35.000000000000000 |
| Operating Temperature-Max (Cel) | 125 |
| Operating Temperature-Min (Cel) | -40 |
| Operating Temperature TJ-Max (Cel) | 125 |
| Operating Temperature TJ-Min (Cel) | -40 |
| Time@Peak Reflow Temperature-Max (s) | 30 |
Submit request
CONTACT REASON
Sourceability North America, LLC
9715 Burnet Rd, Ste 200You can download the user manual and technical specifications for Texas Instruments Incorporated LM78M05CDTX/NOPB in the documentation section.
500-mA, 35-V, linear voltage regulator for 5 V 3-TO-252 -40 to 125
As part of the category Semiconductors and subcategory Semiconductors, LM78M05CDTX/NOPB optimizes energy distribution in electronic devices. Its 500-mA, 35-V, linear voltage regulator for 5 V 3-TO-252 -40 to 125 allows minimizing losses and increasing the overall system efficiency.
As a component of the subcategory Semiconductors, LM78M05CDTX/NOPB ensures stable output voltage even when the load changes. Its 500-mA, 35-V, linear voltage regulator for 5 V 3-TO-252 -40 to 125 makes it a reliable element in multi-level power systems.
