HD3SS215IRTQR
Availability
Design risk
Price trend
Lead time
6-Gbps HDMI 2.0/5.4-Gbps DisplayPort 1.2a 1-to-2 /2-to-1 differential mux supports DDC/AUX switching 56-QFN -40 to 85
| Output | SEPARATE OUTPUT |
| Width (mm) | 8 |
| Length (mm) | 8 |
| JESD-30 Code | S-PQCC-N56 |
| Package Code | HVQCCN |
| Package Shape | SQUARE |
| Package Style (Meter) | CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE |
| Surface Mount | YES |
| Terminal Form | NO LEAD |
| J-STD-609 Code | e4 |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) |
| Terminal Position | QUAD |
| Number of Channels | 4 |
| Number of Functions | 1 |
| Number of Terminals | 56 |
| Terminal Pitch (mm) | 0.5 |
| Package Body Material | PLASTIC/EPOXY |
| Analog IC - Other Type | DIFFERENTIAL MULTIPLEXER |
| Seated Height-Max (mm) | 1 |
| Supply Voltage-Max (V) | 3.6 |
| Supply Voltage-Min (V) | 3 |
| Supply Voltage-Nom (V) | 3.3 |
| Supply Current-Max (mA) | 3.2 |
| Switch-on Time-Max (ns) | 1000.0000000000000000 |
| Package Equivalence Code | LCC56,.32SQ,20 |
| Switch-off Time-Max (ns) | 20000.0000000000000000 |
| Moisture Sensitivity Level | 3 |
| Off-state Isolation-Nom (dB) | 16 |
| On-state Resistance-Max (ohm) | 14.00000000 |
| Peak Reflow Temperature (Cel) | 260 |
| Operating Temperature-Max (Cel) | 85 |
| Operating Temperature-Min (Cel) | -40 |
| On-state Resistance Match-Nom (ohm) | 1.5000000000000000 |
| Time@Peak Reflow Temperature-Max (s) | 30 |
Submit request
CONTACT REASON
Sourceability North America, LLC
9715 Burnet Rd, Ste 200You can download the user manual and technical specifications for Texas Instruments Incorporated HD3SS215IRTQR in the documentation section.
6-Gbps HDMI 2.0/5.4-Gbps DisplayPort 1.2a 1-to-2 /2-to-1 differential mux supports DDC/AUX switching 56-QFN -40 to 85
As part of the category Semiconductors and subcategory Semiconductors, HD3SS215IRTQR optimizes energy distribution in electronic devices. Its 6-Gbps HDMI 2.0/5.4-Gbps DisplayPort 1.2a 1-to-2 /2-to-1 differential mux supports DDC/AUX switching 56-QFN -40 to 85 allows minimizing losses and increasing the overall system efficiency.
As a component of the subcategory Semiconductors, HD3SS215IRTQR ensures stable output voltage even when the load changes. Its 6-Gbps HDMI 2.0/5.4-Gbps DisplayPort 1.2a 1-to-2 /2-to-1 differential mux supports DDC/AUX switching 56-QFN -40 to 85 makes it a reliable element in multi-level power systems.
