Semiconductors

Diodes

Lead Time     10 weeks

CAN bus ESD protection diode

Technical Data

Manufacturer NEXPERIA
MPN PESD1CAN-UX
Polarity BIDIRECTIONAL
Diode Type TRANS VOLTAGE SUPPRESSOR DIODE
Technology AVALANCHE
JESD-30 Code R-PDSO-G3
Configuration Dual
Package Shape RECTANGULAR
Package Style ( Meter ) SMALL OUTLINE
Surface Mount YES
Terminal Form GULL WING
J-STD-609 Code e3
Terminal Finish TIN
Terminal Position DUAL
Additional Feature IEC-61643-321
Number of Elements 2.0000
Number of Terminals 3.0000
Package Body Material PLASTIC/EPOXY
Diode Element Material SILICON
Clamping Voltage-Max (V) 50.0000
Reverse Current-Max (uA) 0.0500
Reverse Test Voltage (V) 24.0000
Breakdown Voltage-Max (V) 30.3000
Breakdown Voltage-Min (V) 25.4000
Breakdown Voltage-Nom (V) 27.8000
Moisture Sensitivity Level 1.0000
Peak Reflow Temperature (Cel) 260.0000
Rep Pk Reverse Voltage-Max (V) 24.0000
Operating Temperature-Max (Cel) 150.0000
Operating Temperature-Min (Cel) -55.0000
Non-rep Peak Rev Power Dis-Max (W) 150.0000
Screening Level / Reference Standard IEC-60134; IEC-61000-4-2, 4-5
Time@Peak Reflow Temperature-Max (s) 30.0000
