SN65HVD12DR

3.3V Differential Transceiver 8-SOIC -40 to 85

Request price

Technical Data

Manufacturer texas instruments inc

MPN SN65HVD12DR

Technology BICMOS

Width (mm) 3.9000

Length (mm) 4.9000

JESD-30 Code R-PDSO-G8

Package Code SOP

Package Shape RECTANGULAR

Package Style ( Meter ) SMALL OUTLINE

Surface Mount YES

Terminal Form GULL WING

J-STD-609 Code e4

Output Polarity TRUE

Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)

DLA Qualification Not Qualified

Interface IC Type LINE TRANSCEIVER

Out Swing-Min (V) 1.5000

Temperature Grade INDUSTRIAL

Terminal Position DUAL

Additional Feature SIGNALING RATE 1 MBPS

Interface Standard EIA-485-A; TIA-485-A; ISO 8482

Differential Output YES

Number of Functions 1.0000

Number of Terminals 8.0000

Terminal Pitch (mm) 1.2700

Driver Number of Bits 1.0000

Input Characteristics DIFFERENTIAL SCHMITT TRIGGER

Package Body Material PLASTIC/EPOXY

Output Characteristics 3-STATE

Receive Delay-Max (ns) 70.0000

Seated Height-Max (mm) 1.7500

Supply Voltage-Max (V) 3.6000

Supply Voltage-Min (V) 3.0000

Supply Voltage-Nom (V) 3.3000

Receiver Number of Bits 1.0000

Supply Current-Max (mA) 15.5000

Supply Voltage1-Max (V) 3.6000

Supply Voltage1-Min (V) 3.0000

Transmit Delay-Max (ns) 300.0000

Package Equivalence Code SOP8,.25

Moisture Sensitivity Level 1.0000

Output Low Current-Max (mA) 8.0000

Peak Reflow Temperature (Cel) 260.0000

Operating Temperature-Max (Cel) 85.0000

Operating Temperature-Min (Cel) -40.0000

High Level Input Current-Max (A) 0.0001

Time@Peak Reflow Temperature-Max (s) 30.0000

Availability In stock
