LMR14050SDDAR
Availability
Design risk
Price trend
Lead time
SIMPLE SWITCHER® 40-V, 5-A, 2.2-MHz step-down converter with 40-μA IQ 8-SO PowerPAD -40 to 125
| Width (mm) | 3.9 |
| Length (mm) | 4.9 |
| Control Mode | CURRENT-MODE |
| JESD-30 Code | R-PDSO-G8 |
| Package Code | HLSOP |
| Package Shape | RECTANGULAR |
| Package Style (Meter) | SMALL OUTLINE, HEAT SINK/SLUG, LOW PROFILE |
| Surface Mount | YES |
| Terminal Form | GULL WING |
| J-STD-609 Code | e4 |
| Terminal Finish | Nickel/Palladium/Gold/Silver (Ni/Pd/Au/Ag) |
| Control Technique | PULSE WIDTH MODULATION |
| Number of Outputs | 1 |
| Temperature Grade | AUTOMOTIVE |
| Terminal Position | DUAL |
| Number of Functions | 1 |
| Number of Terminals | 8 |
| Terminal Pitch (mm) | 1.27 |
| Input Voltage-Max (V) | 40 |
| Input Voltage-Min (V) | 4 |
| Input Voltage-Nom (V) | 12 |
| Package Body Material | PLASTIC/EPOXY |
| Analog IC - Other Type | SWITCHING REGULATOR |
| Output Current-Max (A) | 5 |
| Output Voltage-Max (V) | 36 |
| Output Voltage-Min (V) | 1 |
| Seated Height-Max (mm) | 1.7 |
| Switcher Configuration | BUCK |
| Moisture Sensitivity Level | 2 |
| Peak Reflow Temperature (Cel) | 260 |
| Switching Frequency-Max (kHz) | 2500 |
| Operating Temperature-Max (Cel) | 125 |
| Operating Temperature-Min (Cel) | -40 |
| Time@Peak Reflow Temperature-Max (s) | 30 |
Submit request
CONTACT REASON
Sourceability North America, LLC
9715 Burnet Rd, Ste 200You can download the user manual and technical specifications for Texas Instruments Incorporated LMR14050SDDAR in the documentation section.
SIMPLE SWITCHER® 40-V, 5-A, 2.2-MHz step-down converter with 40-μA IQ 8-SO PowerPAD -40 to 125
As part of the category Semiconductors and subcategory Semiconductors, LMR14050SDDAR optimizes energy distribution in electronic devices. Its SIMPLE SWITCHER® 40-V, 5-A, 2.2-MHz step-down converter with 40-μA IQ 8-SO PowerPAD -40 to 125 allows minimizing losses and increasing the overall system efficiency.
As a component of the subcategory Semiconductors, LMR14050SDDAR ensures stable output voltage even when the load changes. Its SIMPLE SWITCHER® 40-V, 5-A, 2.2-MHz step-down converter with 40-μA IQ 8-SO PowerPAD -40 to 125 makes it a reliable element in multi-level power systems.
