Datasheet

781715007

Conn Wire to Board HDR 7 POS 1.2mm Solder ST SMD Pico-EZmate T/R

Request price

Technical Data

Manufacturer molex llc

MPN 781715007.0000

Option GENERAL PURPOSE

Contact Style SQ PIN-SKT

Mounting Type BOARD

Connector Type BOARD CONNECTOR

Contact Gender MALE

Filter Feature NO

J-STD-609 Code e4

Mixed Contacts NO

Mounting Style STRAIGHT

Contact Pattern RECTANGULAR

Insulator Color BLACK

Contact Material NOT SPECIFIED

Polarization Key POLARIZED HOUSING

Termination Type SURFACE MOUNT

Body Depth (inch) 0.1770

Mounting Option 1 LOCKING

Body Length (inch) 0.4020

Insulator Material POLYAMIDE

Mating Information MULTIPLE MATING PARTS AVAILABLE

Number of Contacts 7.0000

Number of PCB Rows 1.0000

Body Breadth (inch) 0.0550

Durability (Cycles) 10.0000

PCB Contact Pattern RECTANGULAR

Terminal Pitch (mm) 1.2000

Number of Connectors ONE

UL Flammability Code 94V-0

Number of Rows Loaded 1.0000

Contact Finish - Mating NOT SPECIFIED

Insertion Force-Max (N) 30.0000

Withdrawl Force-Min (N) 1.2000

Plating Thickness (inch) 4u

Contact Resistance (mohm) 20.0000

Rated Current (Signal) (A) 1.5000

Insulation Resistance (ohm) 100000000.0000

Mating Contact Pitch (inch) 0.0470

Contact Finish - Termination Gold (Au)

Operating Temperature-Max (Cel) 105.0000

Operating Temperature-Min (Cel) -40.0000

Dielectric Withstanding Voltage (V) 500VAC

Screening Level / Reference Standard UL
