Semiconductors

Multiplexers or Switches

Lead Time 16 weeks

8-Channel/Dual 4-Channel, Low-Leakage, CMOS Analog Multiplexers

Request price

Technical Data

Manufacturer analog devices inc

MPN MAX338CSE+T

Output ( V ) COMMON OUTPUT

Switching ( V ) BREAK-BEFORE-MAKE

Technology CMOS

Width (mm) 3.9000

Length (mm) 9.9000

JESD-30 Code R-PDSO-G16

Package Code SOP

Package Shape RECTANGULAR

Package Style ( Meter ) SMALL OUTLINE

Surface Mount YES

Terminal Form GULL WING

J-STD-609 Code e3

Normal Position ( V ) NO

Terminal Finish Matte Tin (Sn) - annealed

DLA Qualification Not Qualified

Temperature Grade COMMERCIAL

Terminal Position DUAL

Number of Channels 8.0000

Number of Functions 1.0000

Number of Terminals 16.0000

Terminal Pitch (mm) 1.2700

Package Body Material PLASTIC/EPOXY

Analog IC - Other Type SINGLE-ENDED MULTIPLEXER

Seated Height-Max (mm) 1.7500

Signal Current-Max (A) 0.0300

Supply Voltage-Max (V) 20.0000

Supply Voltage-Min (V) 4.5000

Supply Voltage-Nom (V) 15.0000

Switch-on Time-Max (ns) 500.0000

Package Equivalence Code SOP16,.25

Switch-off Time-Max (ns) 500.0000

Moisture Sensitivity Level 1.0000

Off-state Isolation-Nom (dB) 75.0000

On-state Resistance-Max (ohm) 400.0000

Peak Reflow Temperature (Cel) 260.0000

Negative Supply Voltage-Max (V) -20.0000

Negative Supply Voltage-Min (V) -4.5000

Negative Supply Voltage-Nom (V) -15.0000

Operating Temperature-Max (Cel) 70.0000

Operating Temperature-Min (Cel) 0.0000

On-state Resistance Match-Nom (ohm) 4.0000

Time@Peak Reflow Temperature-Max (s) 30.0000

Availability In stock
