Lead Time     12 weeks
Data Sheet     Download TPS7B8133QDRVRQ1 datasheet TPS7B8133QDRVRQ1

Automotive 150-mA, off-battery (40-V), ultra-low-IQ, low-dropout voltage regulator with enable 6-WSON -40 to 150

Technical Data

Manufacturer Texas Instruments Incorporated
MPN TPS7B8133QDRVRQ1
Width (mm) 2.0000
Length (mm) 2.0000
JESD-30 Code S-PDSO-N6
Package Code HVSON
Adjustability FIXED
Package Shape SQUARE
Package Style ( Meter ) SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE
Surface Mount YES
Terminal Form NO LEAD
J-STD-609 Code e4
Regulator Type FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Outputs 1.0000
Terminal Position DUAL
Number of Functions 1.0000
Number of Terminals 6.0000
Terminal Pitch (mm) 0.6500
Input Voltage-Max (V) 40.0000
Input Voltage-Min (V) 3.9750
Package Body Material PLASTIC/EPOXY
Seated Height-Max (mm) 0.8000
Output Current1-Max (A) 0.1500
Output Voltage1-Max (V) 3.3495
Output Voltage1-Min (V) 3.2505
Output Voltage1-Nom (V) 3.3000
Dropout Voltage1-Max (V) 0.6750
Dropout Voltage1-Nom (V) 0.2700
Voltage Tolerance-Max (%) 1.5000
Moisture Sensitivity Level 2.0000
Peak Reflow Temperature (Cel) 260.0000
Operating Temperature TJ-Max (Cel) 150.0000
Operating Temperature TJ-Min (Cel) -40.0000
Screening Level / Reference Standard AEC-Q100
Time@Peak Reflow Temperature-Max (s) 30.0000
Availability In stock

Submit Request

CONTACT REASON

Connect With Us

HEADQUARTERS

Sourceability North America, LLC

9715 Burnet Rd, Ste 200 Austin, TX 78758-5215

FOR GENERAL INQUIRES

Email [email protected]

Phone +1-888-952-9225

Frequently Asked Questions

As part of the category Semiconductors and subcategory Other Semiconductors, TPS7B8133QDRVRQ1 optimizes energy distribution in electronic devices. Its Automotive 150-mA, off-battery (40-V), ultra-low-IQ, low-dropout voltage regulator with enable 6-WSON -40 to 150 allows minimizing losses and increasing the overall system efficiency.

As a component of the subcategory Other Semiconductors, TPS7B8133QDRVRQ1 ensures stable output voltage even when the load changes. Its makes it a reliable element in multi-level power systems.

You can download the user manual and technical specifications for TPS7B8133QDRVRQ1 in the documentation section.

Automotive 150-mA, off-battery (40-V), ultra-low-IQ, low-dropout voltage regulator with enable 6-WSON -40 to 150
