LM20BIM7X/NOPB
Availability
Design risk
Price trend
Lead time
±1.5°C Analog Output Temperature Sensor 5-SC70 -55 to 130
| Housing | PLASTIC |
| Technology | CMOS |
| R0-Nom (ohm) | 160 |
| J-STD-609 Code | e3 |
| Linearity (Cel) (Cel) | 0.40 |
| Terminal Finish | Matte Tin (Sn) |
| Body Height (mm) | 0.9 |
| Mounting Feature | SURFACE MOUNT |
| Termination Type | SOLDER |
| Body Breadth (mm) | 1.25 |
| Accuracy-Max (Cel) (Cel) | 1.5 |
| Number of Terminals | 5 |
| Package Shape/Style | RECTANGULAR |
| Package Body Material | PLASTIC/EPOXY |
| Supply Voltage-Max (V) | 5.5 |
| Supply Voltage-Min (V) | 2.4 |
| Output Current-Nom (uA) | 10 |
| Package Equivalence Code | TSSOP5/6,.08 |
| Sensors/Transducers Type | TEMPERATURE SENSOR,ANALOG,VOLTAGE OUTPUT |
| Operating Current-Max (mA) | 0.007 |
| Body Length or Diameter (mm) | 2 |
| Operating Temperature-Max (Cel) | 130 |
| Operating Temperature-Min (Cel) | -55 |
| Configuration | Remote |
Submit request
CONTACT REASON
Sourceability North America, LLC
9715 Burnet Rd, Ste 200You can download the user manual and technical specifications for Texas Instruments Incorporated LM20BIM7X/NOPB in the documentation section.
±1.5°C Analog Output Temperature Sensor 5-SC70 -55 to 130
As part of the category Semiconductors and subcategory Semiconductors, LM20BIM7X/NOPB optimizes energy distribution in electronic devices. Its ±1.5°C Analog Output Temperature Sensor 5-SC70 -55 to 130 allows minimizing losses and increasing the overall system efficiency.
As a component of the subcategory Semiconductors, LM20BIM7X/NOPB ensures stable output voltage even when the load changes. Its ±1.5°C Analog Output Temperature Sensor 5-SC70 -55 to 130 makes it a reliable element in multi-level power systems.
